Specifications

• ENGINE

  add remove
  • Engine Type:
    Single-Cylinder
  • Cylinders:
    1
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Liquid / Air
  • Valves:
    4
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    SOHC
  • Bore (in):
    2.86
  • Stroke (in):
    2.57
  • Displacement (cc):
    270
  • Starter:
    Electric / Pull
  • Fuel Type:
    Gas
  • Fuel Injector:
    No
  • Carburetor:
    Yes
• TRANSMISSION

  add remove
  • Transmission Type:
    Continuously Variable (CVT)
  • Primary Drive (Rear Wheel):
    Shaft
  • Reverse:
    Yes
  • Transmission Brand:
    Duramatic™
  • Hi / Low Range:
    Yes
  • Adjustable Throttle:
    Not Available
  • Primary Drive (Engine / Transmission):
    Belt
• DRIVE LINE

  add remove
  • Driveline Type:
    4X2
  • Number Of Driveline Modes:
    1
  • Rear Unlocking Differential:
    No
  • Limited Slip Differential:
    Not Available
  • Differential Lock:
    Not Available
  • Rear Solid Axle:
    Yes
• TECHNICAL SPECIFICATIONS

  add remove
  • Width (in):
    41.4
  • Height (in):
    44
  • Wheelbase (in):
    46.4
  • Ground Clearance (in):
    8.3
  • Dry Weight (lbs):
    477
  • Fuel Capacity (gal):
    4.3
  • Engine Displacement to Weight (cc):
    0.57
  • Towing Capacity (lbs):
    500
  • Payload Capacity (lbs):
    400
• SUSPENSION

  add remove
  • Front Suspension Type:
    Independent Double A-Arm
  • Front Travel (in):
    5
  • Front Adjustable Fork Pre-Load:
    Yes
  • Rear Suspension Type:
    Swing Arm
  • Rear Travel (in):
    5
  • Number Rear Shock Absorbers:
    1
  • Front Central Suspension Strut:
    No
  • Front Stabilizer Bar:
    No
  • Steering Damper:
    No
  • Rear Suspension Material:
    Steel
  • Rear Adjustable Rebound Damping:
    No
  • Rear Stabilizer Bar:
    No
  • Air Adjustable:
    No
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Steel
  • Chromed:
    No
  • Front Tire (Full Spec):
    Kenda Pathfinder 22 X 7-10
  • Rear Tire (Full Spec):
    Kenda Pathfinder 22 X 10-10
• BRAKES

  add remove
  • Front Brake Type:
    Hydraulic Disc
  • Rear Brake Type:
    Hydraulic Disc
  • Engine Braking Brand Name:
    Engine Braking System
